TNA-1800SA

The TNA-1800SA Active subwoofer features a HH designed 18-inch low frequency woofer with exceptional high output. Equipped with integrated rigging hardware, the TNA-1800SA can be installed quickly and easily. The TNA-1800SA offers a max SPL of 138 dB and offers a frequency response as low as 32Hz. The TNA-1800SA offers an ideal venue installation or point source solution. Ideal for venues, schools, sports, gyms, hotels and more.

• System Type
  18-inch Active Subwoofer, Direct Radiating, Bass Reflex
• Frequency Response (-10)
  32Hz – 100Hz
• Frequency Response (-3)
  37Hz – 100Hz
• LF Driver
  1 x 18-inch High sensitivity HH designed driver. 4-inch Voice Coil
• Max SPL
  138 dB
• Crossover Frequency
  Active – 70Hz to full range
• Power
  4000W Peak, 2000W Continuous, 1000W RMS
• Input Sensitivity
  0dBu to +10dBu Adjustable
• Input Connector
  Balanced Female XLR
• Output Connector
  Balanced Male XLR (Switchable Full Range/Xover)
• Controls
  Input sensitivity, Crossover frequency, Phase Switch, Variable Delay (0>9.9mS)
• Cabinet
  Acoustically optimised 18mm plywood cabinet with extensive internal bracing
• Finish
  Painted Black (White finish optional, subject to MOQ)
• Mounting Points
  8x M10 Penn Elcom tie down/flying points for optional TNA-BRK3 frame.16x M8 inserts for optional transport wheels
• Grille
  1.5mm Thickness Steel, Hexagonal mesh, acoustic foam lined
• Unit Dimensions (Hwd)
  562 x 600 x 640mm, 22.1″ x 23.6″ x 25.2″
• Unit Weight
  43.5Kg, 95.9 lbs
• Carton Dimensions (Hwd)
  740 x 730 x 765mm, 29.1″ x 28.7″ x 30.1″ , 0.413 M3
• Packed Weight
  51.3Kg, 113.1 lbs
